| Rated voltage | 300/500V |
| Test voltage | 2000V |
| Flexing bending radius | 12.5 x Ø |
| Static bending radius | 12.5 x Ø |
| Flexing temperature | -5º C to +70º C |
| Static temperature | -30º C to +80º C |
| Flame retardant | IEC 60332.1 |
| Insulation resistance | 10 MΩ x km |
| CONSTRUCTIONn x mm2 | OUTER DIAMETERcca. mm | Cu WEIGHTkg / km | CABLE WEIGHTcca. kg / km |
| 1 x 1.5 | 3 | 14,4 | 20 |
| 1 x 2.5 | 3,6 | 24 | 30 |
| 1 x 4 | 4,1 | 38 | 50 |
| 1 x 6 | 4,6 | 58 | 65 |
| 1 x 10 | 6 | 96 | 110 |
| 1 x 16 | 7 | 154 | 165 |
| 1 x 25 | 8,5 | 240 | 242 |
| 1 x 35 | 9,9 | 336 | 350 |
| 1 x 50 | 11,7 | 480 | 482 |
| 1 x 70 | 11,7 | 672 | 662 |
| 1 x 95 | 15,3 | 912 | 885 |
| 1 x 120 | 16,8 | 1152 | 1123 |
| 1 x 150 | 19,2 | 1440 | 1390 |
| 1 x 185 | 21,3 | 1776 | 1733 |
| 1 x 240 | 23,8 | 2304 | 2264 |
| AWG | No. of Cores x Nominal Cross Sectional Area # x mm² |
Nominal Overall Diameter mm |
Nominal Copper Weight kg/Km |
Nominal Weight kg/Km |
| 20 | 1 x 0.5 | 2.1 | 4.8 | 9 |
| 18 | 1 x 0.75 | 2.2 | 7.2 | 11 |
| 17 | 1 x 1 | 2.4 | 9.6 | 14 |
| 16 | 1 x 1.5 | 2.9 | 14.4 | 21 |
| 14 | 1 x 2.5 | 3.5 | 24 | 33 |
| 12 | 1 x 4 | 3.9 | 38 | 49 |
| 10 | 1 x 6 | 4.5 | 58 | 69 |
| 8 | 1 x 10 | 5.7 | 96 | 115 |
| AWG | No. of Cores x Nominal Cross Sectional Area # x mm² |
Nominal Overall Diameter(mm) |
Nominal Copper Weight kg/Km |
Nominal Weight kg/Km |
| 20(7/29) | 1 x 0.5 | 2.2 | 4.8 | 9 |
| 18(7/27) | 1 x 0.75 | 2.4 | 7.2 | 12 |
| 17(7/26) | 1 x 1 | 2.6 | 9.6 | 15 |
About Us
Industry Leadership in Wire and Cable Manufacturing
Henan Pisen Wire and Cable Co., Ltd. stands as a distinguished manufacturer and supplier in the wire and cable industry, delivering high-quality products to over 90 countries worldwide.
Core Manufacturing Capabilities and Quality Assurance
Diverse Product Portfolio: Our extensive range includes Bare Conductors (AAC, AAAC, ACSR), Overhead Insulated Cables, PVC/XLPE Insulated Power Cables, Armored Cables, and more, catering to various industry needs.
Adherence to International Standards: We manufacture products in compliance with GB, IEC, ASTM, BS, EN, DIN, VDE, and other global standards, ensuring consistent quality and reliability.
Production Strength in Numbers
Global Reach: Our products are distributed across major markets, including the Middle East, Africa, Southeast Asia, South America, Europe, Australia, and New Zealand.
Skilled Workforce: We have trained over 80 sales professionals to provide expert guidance and support to our clients.
Commitment to Sustainability
Pisen Cable is dedicated to environmental stewardship. We utilize eco-friendly materials, such as recyclable wooden cable reels, to minimize our ecological footprint and promote sustainable practices.
Customer Collaboration Process
Global Service Capabilities
With a robust international presence, Pisen Cable is equipped to support clients worldwide, offering localized services and solutions that adhere to regional standards and requirements.
Partner with Pisen Cable
Experience the reliability and excellence of Pisen Cable's products and services. Contact us today to discuss how we can meet your wire and cable needs with precision and professionalism.
FAQ
Who are we?
Henan Pisen Wire and Cable Co., Ltd. is a professional manufacturer and supplier of cables and wires, serving over 90 countries with a commitment to quality and innovation.
How can we guarantee quality?
We adhere to international standards such as GB, IEC, ASTM, BS, EN, DIN, and VDE, implementing rigorous quality control measures throughout our manufacturing processes.
What can you buy from us?
Our product range includes Bare Conductors (AAC, AAAC, ACSR), Overhead Insulated Cables, PVC/XLPE Insulated Power Cables, Armored Cables, Building Wires, and more.
Why should you buy from us and not from other suppliers?
Pisen Cable offers a combination of extensive industry experience, adherence to international quality standards, a diverse product portfolio, and a commitment to customer satisfaction, setting us apart from competitors.
What services can we provide?
We provide consultation, product customization (OEM services), stringent quality assurance, efficient logistics support, and dedicated after-sales service to meet our clients' diverse needs.
Enhance your electrical installations with Pisen Cable's H05V series wires. Contact us today to discuss your project needs and discover how our solutions can provide reliability and compliance for your applications.
