Name | Rated Voltage | No. of Core | Nominal Section Area | Application |
- | V | - | mm2 | - |
Light-type Rubber Sheathed Flexible Cable | 300/500 | 2,3 | 0.3-0.5 2,3,4,5 |
For portable electrical instruments, equipments and tools; |
Medium-type Rubber Sheathed Flexible Cable | 300/500 | 2,3,4,5 | 0.75-6 | For portable electrical instruments, equipments and tools; affording larger external forces |
3+1 | 1.5-6 | |||
Heavy-type Rubber Sheathed Cable | 450/750 | 1 | 1.5-400 | For portable electrical instruments, equipments, affording larger external force, weather-resistance and oil-resistance; |
2 | 1-95 | |||
3,4 | 1-150 | |||
5 | 1-25 | |||
3+1 | 1.5-150 |
